Siemens LME44.057C2- 230V
Siemens Part Number:BPZ:LME44.057C2
Overview
LME44.057C2 burner controlsare used for the startup and supervision of 1- or 2-stage gas or gas/oil burners in intermittent operation (of small to medium capacity operation, with or without a fan in intermittent.)
The flame is supervised by an ionisation probe or flame detector with the ancillary unit, AGQ3A27 for gas/oil forced draft burners or blue burning flames with blue-flame sensors QRC...
Siemens LME44.057C2 Burner Control Box Applications
Typical application: This LME44.057is used to supervise 2 stage forced draft burners, with actuator control.
Features
- Prepurge Time: 9s
- Safety Time: 5s
- Pre-ignition time: 2s
- The LME's housing is made up of heat resistant and flame retardant plastic.
- Supply Voltage: 230VAC
- Undervoltage Detection
- IP Rating: IP40
- Operation Temperature: -20 - +60 °C
- Mounting Position: Optional
- Weight: Approx. 160g
