Manufacturer: Siemens
Siemens Part Number: BPZ:AGK11.6
Use for burner controls with continuous phase
- Colour: Silver-grey RAL 9001
- Made of impact-proof and heat-resistant plastic
- Accommodates (in addition to the 12 connection terminals):
- 3 neutral terminals, pre-wired to terminal 2, the neutral input
- 4 earth conductor terminals, joining in a lug for earthing the burner
- 2 auxiliary terminals marked «31» and «32»
- With 2 holes in the baseplate of the AGK11 for cable entry
- Provided with catches on the 2 narrow sides which audibly engage when the burner control is plugged in
- To disengage, a screwdriver must be slightly tilted in the guiding slots
- Neutral and auxiliary terminals with self-tapping screws
- Connection terminals with self-locking screws
- Supplied with terminals open to facilitate mounting
- The burner control is secured to the burner with fixing screws M5
Dimensions
