Siemens LMV36.300A2 Burner Management System
Siemens LMV36.300A2
The LMV36 provides all supervisory functions required for forced draft burners of medium to high capacity operating on a single fuel and using integrated communication interfaces affords convenient diagnostics, parameter settings and incorporation on the automation system level.
Microprocessor-controlled for single-fuel burners of any capacity for continuous and intermittent operation, with electronic fuel-air ratio control, up to 2 actuators and integrated gas valve proving.
LMV36.300 A2 Features
This Siemens burner control box features a burner management system complete with valve proving system, electronic fuel/air ratio control, Modbus interface, BCI for connection to a display. The LMV36.300 control box also has a designed lifetime of 250,000 startup cycles which, under normal operating conditions correspond to approx. 10 years of usage.
Specifications
- Voltage: 230VAC
- Perm. mains primary fuse: Max. 16AT
- Mode of operation: Type 2B in accordance with DIN EN 60730-1
- Voltage Detection (ON): 180V-253VAC
- Voltage Detection (OFF): <80VAC
- Temperature: -20° C - +60° C
Dimensions
| Control Box | Height | Width | Depth |
|---|---|---|---|
| LMV36.300 A2 | 230mm | 135mm | 60mm |
-
