Siemens QRA73.A27 UV Flame Detector - Self Checking

Siemens QRA73.A27 UV Cell 230v Includes Mounting Clamp

The detectors UV cell is located behind a swivelling shutter at the front end of the detector tube which is flanged to the housing. A quartz-glass window protects the tube and the shutter against dirt. The detectors housing accommodates a stepper motor to drive the shutter and the electronics to control the shutter. Using the AGG16.C adapter, this flame detectors can be mounted either directly on the burner, on a viewing tube or on a combustion chamber viewing hole.

Specifications:

• Sensitivity: Normal
• Detector Tube Length: 125mm
• Mains Voltage: AC 230V
• Spare UV Tube: AGR 502 4065 0
• Average life of UV cell: 10,000 hours
• Degree of protection: IP65
• Weight approx: 700 g
• Lead Required (not included): Siemens AGM23

Average life of this self checking UV Cell is 10,000 hours if used below 50¬. Use at ambient temperatures above this will significantly reduce the life of the cell.
